Coating Pan

Product Description

Riddhi Coating Machine is available in 12 18 24 30 36 42 48 60 or 72   size SS Pan  Pan is made of 10 Gauge SS 304 or SS 316 The Base Plate of Pan is SS304 6 MM thick The Pan is provided with 3 Baffles for 36 inches 4 Baffles for 48 inches  Machine is made of thick MS angle frame totally enclosed with SS Cladding with Standard Gear Box Motor and Hot Air Blowing arrangement outside Fabricated structure and all arrangements  except electric control air filter and SS Pan are inside the enclosure which makes simple cleanable outside covering Machine is mounted on dynamounts which avoids foundation

All Riddhi Coating Machines are provided with interlocked electrical circuit so that heaters can be operated only after blowers are made ON to avoid burning of heaters SS Coating Pan mouth ring is welded at their rim cavities to avoid collection of dirt or contaminated drug Riddhi Coating machine can be provided with Redicon  Elecon  Gear Box and NGEF Remi  Siemens  Motor and all electricals controls are of Siemens or L  T make Thermostat control can be provided on demand On Customer demand  Gear box and Electricals including motors can be provided  local make for economic purpose

CONTROL PANEL

• With Pan On  OFF light indicator and Push button
• Digital Temperature Indicator with Thermostat
• With Blower On  Off light indicator Push Button

 BLOWER

300 CFM FOR 24 AND 36 500 CFM FOR 48 with dynamic Balancing with 15 KW  2 heaters for 300 CFM and 45 KW 3 heaters for 48 is advisable Insulation 2 blower with flexible pipe with Fishtail Nozzle can be supplied

Technical Details
